Product Description
Product info:
- 2-channel line driver/output converter with bass restoration
- works with factory and aftermarket systems
- selectable ground isolation modes: GND, ISO, 200-ohm
- preamp and speaker-level inputs
- selectable input signal grounding: balanced, unbalanced
- variable input gain control with Max indicator light
- speaker-level inputs handle up to 40V (400 watts RMS)
- selectable speaker input impedance loads: 20, 60, or 20k ohms
- EPICENTER bass restoration
- recreates missing low-frequency signal content
- ParaBASS controls adjust center-frequency and width of bass processing
- selectable Programmable Frequency Match (PFM) 12 dB/octave subsonic filter: off, 15 Hz, 24 Hz
- variable output gain control with Max indicator light
- outputs up to 9.5 Vrms
- selectable maximum output peak voltage limiter: 5V, 7.5V, 10V
More info:
- ACR-4 wired remote included
- selectable turn-on trigger modes: 12V remote, DC offset (GTO), audio signal detect
- remote 12V trigger output
- wiring, fuse, and hardware not included with device
- 18-gauge power and ground leads and a 1-amp fuse recommended
- dimensions: 8" W x 1" H x 3" D
- warranty: 1 year
